Description
"The Oil Filter Housing O-Ring is a top seller"
An O-ring on a motorcycle is a circular sealing component used to prevent leaks and keep fluids contained within various parts of the bike. It is commonly made from rubber or synthetic materials and is employed in applications such as engine components, fuel systems, and hydraulic systems. The O-ring provides a reliable seal by compressing between two surfaces, helping to maintain pressure and prevent the escape of fluids or ingress of contaminants.
Product Diagram
ENGINE CASING diagram - Lexmoto RX2 125 E55 - SR125-3-E55
| Ref | Item Name | Price | ||
|---|---|---|---|---|
| 1 |  |
Flanged Hex Bolt M6 M6 x 30mm BLT078 x 1
|
||
| 2 | |
Flanged Hex Bolt with Shank M6 x 40mm BLT079 x 1
|
||
| 4 | |
Clutch Actuator Arm CLAA029 x 1
|
||
| 5 | |
Oil Seal 18 x 12 x 5mm for SY125-10-SE-E5, ZS125-39-E5 OLSL110 x 1
|
||
| 6 | |
Clutch Arm Spring SPNG250 x 1
|
||
| 7 | |
Clutch Actuator Arm Roll Pin ZY125 SPLPN021 x 1
|
||
| 8 | |
Right Engine Casing ENGCR099 x 1
|
Soon | |
| 9 | |
Oil Dipstick OLDP002 x 1
|
||
| 10 | |
Dipstick O Ring 18.7 x 25.7 x 3.5mm for ZY125-E4 ORNG050 x 1
|
||
| 11 | |
Engine Dowel 8 x 14mm DWL001 x 1
|
||
| 12 | |
Clutch Cable Retaining Bracket BRCKT366 x 1
|
||
| 13 | |
Right Crankcase (Clutch) Cover Gasket ZY125 for ZS125-48F,ZS125-48E GSKCR024 x 1
|
||
| 14 | |
ZY125-E4 Flanged Hex Bolt M6 x 15mm BLT194 x 1
|
||
| 15 | |
Stator Cable Bracket BRCKT102 x 1
|
||
| 16 | |
Left Crankcase Cover Gasket ZY125 GSKCL019 x 1
|
||
| 17 | |
Left Engine Casing ENGCL105 x 1
|
||
| 18 | |
Left Black Crankcase Plug ZY125 CRCP015 x 1
|
||
| 19 | |
O-Ring 27.4 x 32.7 x 2.65mm ORNG040 x 1
|
||
| 20 | |
Black Engine Timing Check Plug ZY125 ENGTP005 x 1
|
||
| 21 | |
O-Ring 13.2 x 18.5 x 2.65mm ORNG041 x 1
|
||
| 22 | |
Hex Bolt M6 x 45mm BLT080 x 1
|
||
| 23 | |
Flanged Hex Bolt with Shank M6 x 35mm BLT100 x 1
|
||
| 25 | |
Left Engine Casing ENGCL107 x 1
|
Soon | |
| 26 | |
Oil Filter OLF026 x 1
|
||
| 27 | |
Oil Filter Housing O-Ring ORNG088 x 1
|
||
| 28 | |
Oil Filter Cap OLFC032 x 1
|
||
| 29 | |
Water Pump Gasket GSKWP002 x 1
|
||
| 30 | |
Water Pump Cover WTPMP027 x 1
|
||
| 31 | |
Dustproof Cap CPCVR058 x 1
|
||
| 32 | |
Flanged Hex Bolt Inlet Manifold Bolt M6 x 20mm BLT070 x 1
|
||
| 35 | |
Bolt M6 x 22mm BLT978 x 1
|
||
| 36 | |
Dustproof Cap CPCVR063 x 1
|
Soon |
More Product Diagrams
This part appears on 8 other diagrams
Compatibility
| Manufacturer | Model | Diagram |
|---|---|---|
| Lexmoto | LS-Z E55 [ZS125-39-E55] | View parts diagram |
| LS-Z Euro 5 [ZS125-39-E5] | View parts diagram | |
| LXR 125 E55 [SY125-10-E55] | View parts diagram | |
| LXR 125 Euro 5 [SY125-10-E5] | View parts diagram | |
| LXR 125 SE E55 [SY125-10-SE-E55] | View parts diagram | |
| LXR 125 [SY125-10] | View parts diagram | |
| LXR SE 125 Euro 5 [SY125-10-SE-E5] | View parts diagram | |
| LXR SE 125 Euro 5 [SY125-10-SE-V2] | View parts diagram | |
| LXR SE 125 [SY125-10-SE] | View parts diagram | |
| LXS 125 E55 [TR125-GP2-E55] | View parts diagram | |
| LXS 125 Euro 5 [TR125-GP2-E5] | View parts diagram | |
| R66S E55 [SR125-2-E55] | View parts diagram | |
| RSS 125 Euro 5 [TR125-3-E5] | View parts diagram | |
| RSS 125 Scrambler Euro 5 [TR125-3-S-E5] | View parts diagram | |
| RX1 125 E55 [ZS125-86C-E55] | View parts diagram | |
| Mitt | MITT 125 GP 2 [MITT125GP2] | |
| MITT 125 GP [MITT125GP] | ||
| Taro | TR125-3 | |
| UM | Commando Classic 125 [UM125-CL] | View parts diagram |
| Renegade Commando 125 [UM125-CO] | View parts diagram | |
| Renegade Sport S 125 [UM125-RS] | View parts diagram | |
| Vegas 125 [UM125-VG] | View parts diagram | |
| Zongshen | ZS125-39 | |
