VLVSB161"Another great Valve Rocker"
A valve shim is a small, precision-machined metal disc used in a motorcycle's engine to adjust the clearance or gap between the valve and its actuator, typically the rocker arm or camshaft. Shims are placed between the valve stem and the rocker arm or cam follower to achieve the correct valve clearance, which is crucial for optimal engine performance and efficiency. They come in various thicknesses to accommodate different clearance specifications and are essential for maintaining proper valve timing and preventing excessive wear.
| Ref | Item Name | Price | ||
|---|---|---|---|---|
| 1 | ![]() |
Bolt M6 x 16mm BLT967 x 1
|
£1.99 | |
| 2 | ![]() |
Cam Chain Guide Plate CMCG059 x 1
|
£3.49 | |
| 3 | ![]() |
Dowel 28.5 x 10mm DWL056 x 1
|
£2.49 | |
| 4 | ![]() |
Bolt M6 x 22mm BLTCH026 x 1
|
£8.99 | |
| 5 | ![]() |
Bolt M6 x 6mm BLT983 x 1
|
£1.99 | |
| 6 | ![]() |
O-Ring D9.6 x 1.7mm ORNG134 x 1
|
£1.99 | |
| 7 | ![]() |
Cam Chain Tensioner CMCT058 x 1
|
£9.99 | |
| 8 | ![]() |
Cam Chain Tensioner Gasket GSKCT026 x 1
|
£1.99 | |
| 9, 11 | ![]() |
Cam Chain Guides CMCG060 x 1
|
£12.99 | |
| 10 | ![]() |
Timing / Cam Chain CMCHN064 x 1
|
£25.99 | |
| 12 | ![]() |
Rocker Arm RKA058 x 1
|
£14.49 | |
| 13 | ![]() |
Valve Shim/Bucket VLVSB161 x 1
|
£1.99 | |
| 14 | ![]() |
Inlet/Exhaust Valve Spring Seat VLVSS028 x 1
|
£2.49 | |
| 15 | ![]() |
Valve Spring VLVS056 x 1
|
£3.99 | |
| 17 | ![]() |
Inlet/Exhaust Valve Spring Seat VLVSS029 x 1
|
£2.49 | |
| 18 | ![]() |
Inlet Valve VLVIN058 x 1
|
£7.49 | |
| 19 | ![]() |
Rocker Arm RKA059 x 1
|
£14.49 | |
| 20 | ![]() |
Exhaust Valve VLVEX051 x 1
|
£11.49 | |
| 21 | ![]() |
Camshaft CMS072 x 1
|
£30.99 | |
| 23 | ![]() |
Rocker Arm Shaft RKAS048 x 1
|
£2.99 | |
| 24 | ![]() |
Camshaft Bracket BRCKT412 x 1
|
£14.99 | |
| 25 | ![]() |
Bolt M6 x 12mm BLT861 x 1
|
£2.49 | |
| 26 | ![]() |
Timing / Camshaft Sprocket 34T CMCSPK005 x 1
|
£8.99 |
| Manufacturer | Model | Diagram |
|---|---|---|
| Lexmoto | D2 E55 [GC125T-3A-E55] | View parts diagram |
| XDV 125 E55 [LJ125T-18A-E55] | View parts diagram | |
